Constructed Bolted Steel Potable Water Storage Tank

Shijiazhuang Zhengzhong Technology Co., Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Constructed Bolted Steel Potable Water Storage Tank

Brand Name : CEC TANKS

Model Number : W

Certification : ISO 9001:2008, AWWA D103 , OSHA , BSCI

Place of Origin : China

MOQ : 1set

Price : $5000~$20000 one set

Payment Terms : L/C, T/T

Supply Ability : 60 sets per month

Delivery Time : 10-30 days after deposit received

Packaging Details : PE poly-foam between each two steel plates ; wooden pallet and wooden

Coating thickness : 0.25mm~0.40mm , two layer of coating internal and external

Steel grade : ART 310

Size Of Panel : 2.4M * 1.2M

Capactiy available : 20 m3 to 20,000 m3

Easy to clean : Smooth, glossy, inert, anti-adhesion

Easy to cle : Smooth, glossy, inert, anti-adhesion

Warranty period : 2 years free of charge

FeatureEco-friendly : Durability

Capactiy availabl : e20 m3 to 20,000 m3

Impact : ResistanceExcellent

Installation : By jacking machine or steel pole, fast in installation

Contact Now

Health and safety potable water storage tank plays an important role in drinking water and potable water storage. All our bolted steel potable water storage tank is certificated and approved by NSF/ ANSI 61. This gives customers the assurance they need when installing storage tanks for public water systems. Center Enamel quality assurance measures and facility inspections help to ensure our tanks continue to deliver reliable, high-quality performance.

Bolted Steel Potable Water Storage Tank

Bolted steel potable water storage tanks are fusing two materials at 820°C-930°C high temperature to achieve the best properties of both the strength and flexibility of steel and the corrosion of resistance of glass. Glass-Fused-to-Steel tanks can provide many advantages over standard epoxy or welded painted storage tanks. Glass-Fused-to-Steel technology is the premium coating technology in the storage tanks market.

Bolted Steel Potable Water Storage Tank Specifications

Coating color dark blue, dark green, white, and customized
A standard steel plate size effective size 2400mm x 1200 m
Steel plates thickness 3mm - 12mm, depends on the diameter & height
Coating thickness 0.25mm - 0.4mm, two coating internal and external
Acid and alkalinity proof standard coating suits for PH3 - PH11, special coating suits for PH1 - PH14
Adhesion 3,450N/cm
Elastic same as steel sheet , around 500KN/mm
Hardness 6.0 Mohs
Service life >30 years
Spark test >1500 V
Permeability gas and liquid impermeable
Easy yo clean smooth, glossy, inert, anti-adhesion
Corrosion resistance

excellent ! Suitable for waste water salt water, sea water, high sulfur crude oil, salt fox, organic and inorganic compounds

Bolted Steel Potable Water Storage Tank Manufacturer

Center Enamel Co., Ltd is not only the first Glass-Fused-to-Steel Tanks manufacturer and supplier in China, but also the most experienced Glass-Fused-to-Steel tanks manufacturer in all of Asia. Center Enamel Glass-Fused-to-Steel tanks engineering & design, product testing and quality system are in strict accordance with AWWA D103-09, OSHA, ISO/EN 28765, NSF61 and NFPA etc. international standards. CEC Glass-Fused-to-Steel tanks are widely used in drinking/potable water, industrial effluents, municipal sewage, bio-energy, landfill leachate, agriculture etc. applications. Until 2018, Center Enamel Glass-Fused-to-Steel tanks have been exported to more than 60 countries including USA, Australia, Canada, Malaysia, Indonesia, Russia, UAE, Panama, India and South Africa etc. The superior product quality and prompt service gain us worldwide recognition.

Bolted Steel Potable Water Storage Tank Project References

Constructed Bolted Steel Potable Water Storage Tank


Product Tags:

0.40mm Constructed Water Storage Tank



Anti Adhesion Water Storage Tank


Quality Constructed Bolted Steel Potable Water Storage Tank wholesale

Constructed Bolted Steel Potable Water Storage Tank Images
